Hydraulic Gantry Tarping System
Regular price
$9,460.00 USD
The O’Brian Magnum roll off tarp system is designed for reliable, long-term performance in demanding waste and construction environments. Featuring self-lubricating pivots, solid steel construction, and a low-maintenance design, the Magnum covers containers from 10 to 50 cubic yards with consistent, dependable operation.
Why Magnum Outperforms Everything Else
- Never Grease Again – Self-lubricating bushings at all pivot points eliminate bi-weekly greasing
- Works When Damaged – Upper arms stay operational even when bent, unlike telescoping systems that fail completely
- Built to Absorb Abuse – 3/4″ solid steel elbows withstand extreme shock loads and impacts
- Covers 10-50 Yard Containers – One system handles 20, 30, 40, and 50-yard containers up to 24′ long
- American-Made Quality – Built entirely in-house to ISO 9001-2000 standards since 1961
Proven Durability That Saves You Money
Built with 1/4″ thick Grade A5 steel arms designed for decades of service. The Magnum’s solid steel construction offers significantly lower cost of ownership compared to imported tombstone-style systems.
Real Cost Savings:
- Zero greasing = 2-3 hours saved per month, per truck
- Damage-resistant design = Fewer repairs and downtime
- Self-lubricating bushings = Components last 3-5x longer
- Made in USA = Available parts and expert support when you need it
Technical Specifications
- Coverage Range: 10-50 cubic yards
- Container Length: Up to 24 feet
- Arm Material: 1/4" Grade A5 steel or aluminum
- Elbow Construction: 3/4" solid steel plate
- Weight (installed): ~1,250lbs
- Pivot System: Self-lubricating / greaseless
- Control Options: Joystick or lever inside cab
- Manufacturing Rating: ISO 9001-2000 certified. 100% MADE IN THE USA
What’s Included With Every Magnum Tarp System
- Complete arm assembly with protective deflectors
- Self-lubricating pivot assembly (no grease required)
- Heavy-duty hydraulic cylinders
- Control system (joystick or lever)
- Installation hardware and brackets
- Heavy-duty Titan mesh tarp (strongest available)
- Comprehensive installation support
- O’Brian warranty and lifetime technical support
